U807

Product Features

Fabricated of #22 gauge stainless steel with a #4 satin finish

Holds 1300 single fold towels

Secured with pin tumbler lock, keyed like all AJW cabinets

Made with heavy duty piano type hinges

Product Specs

Cabinet: #22 ga. stainless steel with #4 satin finish. Striker tabs prevents damage to mounting surface when cover is closed. (Unibody design)

Cabinet Back: #22 ga stainless steel with embossed towel guides.

Hinges: Full length, heavy duty, stainless steel , piano type hinge. (Welded, no rivets)

Locks: Pin tumbler, commercial quality, keyed like all other AJW cabinets.

Paper Dispenser: Area is hemmed to prevent paper tearing and injury.

Overall Size: 4 5/8"W x 7 3/4"H x 3"D

117mm x 196mm x 76mm

Capacity: 1300 singlefold sheets

Installation Instruction

Provide an area on mounting surface at desired or specified location. Open cover and place unit against wall and transfer mounting points after checks out to be level and is at the proper mounting height. Secure unit to surface with proper fasteners, fill

U807

Single Fold Toilet Tissue Dispenser - Surface Mounted





Technical documents
