U210 Series

Product Features

Fabricated of #22 gauge stainless steel with a #4 satin finish

Holds 100 fl. oz of liquid soap or hand sanitizer

Holds 600 c-fold or 800 multifold towels

Mirror is fabricated with 1/4" plate glass

Uni-door construction available see model U2104

Product Specs

Cabinet Body: Fabricated of #22 ga stainless steel with a #4 satin finish.

Flange: Fabricated of #22 ga stainless steel with #4 satin finish. One piece construction without miters or welds, returns are 1/4" to wall for maximum rigidity.

Cabinet Back: Fabricated of stainless steel with multiple welds to cabinet body for maximum rigidity.

Door: 1/4" plate glass with a 15 year warranty against silver spoilage, with top and bottom s/s channel.

Soap Tank: #20 ga stainless steel fully welded construction. Removable for easy servicing and cleaning. All purpose chrome on brass bellows valve is included. Tank capacity is 100 fluid ounces.

Towel Dispenser: Hemmed edges to prevent towel tearing and injury.

Shelf: Fabricated of #22 ga stainless steel #4 satin finish.

Hinges: Full length stainless steel piano type hinge.

Locks: Pin tumbler type, keyed like all other AJW items.

Collars: #22 ga stainless steel finished to match cabinet for semi-recessing or surface mounting.

Overall Size: 17 1/4"W x 30"H x 4 1/4"D

(438mm x 762mm x 108mm)

Wall Opening: 15 3/4"W x 28 1/2"H x 4"D

(400mm x 648mm x 102mm)

Towel Capacity: 600 c-fold or 800 multifold

U210-S2: semi-recessed. 2" collar, with 2" (51mm) wall opening.

U210-SM: Surface mounted collar.

Options:

-R: Refill Indicator

Installation Instruction

Coordinate installation with architect or contractor to avoid interference with pipes, vents etc. Provide a wall opening 15 3/4"W x 28 1/2"H. Depth will depend on mounting style. See specifications. If a collar is required place over back of cabinet befor

U210

C-fold/Multifold Towel & Soap Dispenser Combination - Recessed
